PARAMETRIC · 3D · STEP
Egg Generator
Specify height, max diameter, and peak bulge position to generate an egg STEP file.
HOW-TO How to Generate an Egg STEP File +
- Enter the total height, maximum diameter, and bulge peak position
- Calculated values update in real time as parameters change
- Click "Download STEP File" or "Preview STEP Model"
- If you selected "Download STEP File", the STEP file will be saved automatically
- If you selected "Preview STEP Model", check the 3D model, then click "Download STEP File" manually
SAMPLE
STATIC · DEFAULT-VALUE MODEL
CALCULATED · SPEC
AUTO-COMPUTED
Zw
33.00mm
Widest Point Height
r
20.00mm
Max Radius
h/d
1.38-
Aspect Ratio
PARAMETERS
Enter Dimensions
SPONSORED
Useful products for makers
- Digital Caliper Measuring Tool(opens the Amazon page in a new tab)
- Bambu Lab PETG HF Filament(opens the Amazon page in a new tab)
- Bambu Lab A1 mini(opens the Amazon page in a new tab)
- Bambu Lab P2S Combo(opens the Amazon page in a new tab)
As an Amazon Associate, meta-matic earns from qualifying purchases.
ABOUT · STEP
The STEP file (.step / .stp) is a standard 3D CAD format that retains dimensional and topology data. Compatible with major CAD software including Fusion 360, SolidWorks, and FreeCAD.
- Full-scale solid (mm units)
- Editable dimensions and post-processing in CAD
- Convertible with a slicer for 3D printing
